■Specifications

Model No.
∗ 1
Pressure range
Rated pressure range
Set pressure range
Setting/Display resolution
Power supply voltage
Current consumption
Power supply voltage for sensor
Power supply current for sensor
Input signal
Number of input
Sensor
input
Input protection
Automatic identification
Hysteresis
Output style
Number of output
Max. load current
Switch
output
Max. applied voltage
Residual voltage
Output protection
Response time
Anti-chattering function
Repeatability
Indicator accuracy
o
(Ambient temp. 25 C)
Display method
Indicator
Auto-shift input
Enclosure
Ambient temp. range
Environ
Ambient humidity
ment
Withstand voltage
Insulation resistance
Temp. characteristics
Connection
Standard
Power supply/Output connection
cable
Material
Weight
∗1: Select pressure range by the initialization.
∗2: Over current on Vcc side and 0 V side of sensor input connector results in breakage of internal parts of controller.
∗3: Pressure sensor that automatic identification can be applied is only "PSE530 series". Refer to page 18, 26 "Automatic identification
function" for detail.
For positive pressure For vacuum
0 to 1 MPa 0 to -101 kPa
-0.1 to 1 MPa 10 to -101 kPa
0.1 kPa
12 to 24 VDC, ripple (p−p) 10% or less (Protected against inverse connection)
55 mA or less (Except for consumed current of sensor part)
Max. 40 mA or less (Max. total consumed current is 100 mA for inputting 4 sensors)
1 to 5 VDC (Input impedance: Approx. 800 kΩ)
With over voltage protection (Applicable to voltage up to 26.4 V)
Hysteresis mode: Variable
Window comparator mode: Fixed 3 digits
NPN or PNP open collector output
5 outputs (2 outputs for sensor input CH1, and 1 output for each CH2 to CH4)
1 V or less (At 80 mA load current)
Display for measured value: 4 digits, 7-segment (Orange)
Display for channel: 1 digit, 7-segment (Red)
Non-voltage input (Reed or solid state), Input 10 ms or less,
Setting ON/OFF is possible independently
Front part: IP65 (At panel mounting), Others: IP40
o
Operation: 0 to 50 C, Storage: -10 to 60
Operation, Storage: 35 to 85%RH (No condensation)
1000 VAC, 1 minute Between lead block and case
50 MΩ or more (At 500 VDC) Between lead block and case
Power supply and output connection: 8P connector, Sensor connection: e-con
Oil resistance vinyl cabtyre cable 8 cores φ4.8 2 m
Body: PBT, Display: Transparent nylon, Rubber cover for the back: CR
113 g (Power supply and output lead wire cable included)
55 g (Power supply and output lead wire cable not included)
-36-
PSE20∗
For low pressure
0 to 101 kPa
-10 to 101 kPa
0.1 kPa 0.1 kPa
[Power supply voltage] -1.5 V
4 inputs
∗ 3
Provided
80 mA
30 VDC (At NPN output)
With short circuit protection
5 ms or less
20, 160, 640 ms selectable
±0.1%F.S. ±1 digit
±0.5%F.S. ±1 digit
Light when ON (Red)
o
C (No condensation or freezing)
o
±0.5%F.S. (25 C reference)
CE, RoHS
Sectional area of conductor: 0.15 mm
Outside diameter of insulator: 0.9 mm
For compound
-101 to 101 kPa
-101 to 101 kPa
0.001 MPa
∗ 2
2
