Setting of Special Function

○Fine adjustment function of displayed value
This makes no dispersion on CH1 to CH4 each output value, and make same displayed value.
It is possible to do fine adjustment within ±5%R.D. range of the reading data on the displayed value of
pressure sensor.
•Press the
and
simultaneously for 2 seconds or longer to display
[FSt].
If fine adjustment is unnecessary, press the
button while [FSt] is displayed. Move to copy function.
•Press the
or
•[FSt] and preset pressure measured value are in turn.
•Increase or decrease value by press the
button.
(It is possible to increase/decrease within ±5%R.D.)
•Check the value, then press the
[FSC] and the adjusted value (%) are displayed in turn.
•Press the
button to return display of [FSt]. Perform display of [FSt] setting of other channels like the
above by press the
•After setting of other channels in [FSt] display is completed, press the
Move to copy function.
∗: When fine adjustment mode is conducted, pressure setting value is sometimes changed by ±1 digit
○Copy function
1, 5 items such as pressure setting value, pressure range, display unit, output style and response time are
copied.
2, If copied from CH1 to CH2, CH3 and CH4, CH1 OUT1 information is copied.
CH2, CH3 and CH4 information are copied only into OUT1 of CH1 if copied from CH2, CH3 and CH4 to
CH1.
•[CPy] is displayed. Selection of channel to be copied displayed in channel
indicator by press the
•Press the
button in case copy mode setting is not necessary.
Move to auto-shift function.
•Press the
button so that the channel display of a copied material changes
from blink to lighting.
•[CPy] and the channel to be pasted will flicker alternately. Next, select channel to be pasted by press the
or button.
•Press the
button, and return to [CPy] display.
•Again press the
•After setting is completed, move from [CPy] display to auto-shift mode.
∗: When copy function is conducted, pressure setting value is sometimes changed by ±1 digit.
buttons are pressed
button to select channel, and press the
or
button.
or button.
or button.
or button and the same operation is repeated to copy other channel.
button.
-24-
button there.
No.PS##-OMH0006-C
