○Initial setting
Select the setting channel by pressing the
longer. Initialize can get started. Initial setting is required for each channel.
1, Setting of pressure range
•Select the pressure range suitable for the sensor connected.
•Press the
or
∗: When automatic identification mode is set, it is changed to pressure range of connected pressure sensor (Series PSE530 only)
when power is supplied.
∗: When range setting is changed, pressure set value changes. So conduct pressure setting again.
2, Selection of display unit (with unit conversion function)
The indication unit can be selected freely.
Press the or
Press the button to set and to move to setting the output mode.
LCD display
For compound and vacuum
Unit label
In order to display the selected unit, the unit label according to the pressure range or the display
unit is attached.
Select and use an applicable label from the following table.
•In case [M] is assigned to unit specification in model indication.
Use the suitable label in the above labels by setup of the display unit.
•In case [M] is not assigned to unit specification in model indication.
The following unit displays light according to the setting of the pressure range.
LCD display
Unit display
3, Setting of output style
1)The output style for OUT1 is set.
•Press
or
Next, press the
2)The operating mode and the output style for OUT2 is set. (only CH1)
•Press
or
button and select the pressure range. Press the
button will change the unit and will automatically convert set values.
For low pressure
For positive
(Compound)
button and select the normally open or the normally closed.
button to set.
button and the
button and keep pressing the
2
kPa kgf/cm bar
2
kPa kgf/cm bar
2
MPa kgf/cm bar
(Vacuum) (Low pressure)
kPa
button to set, as in OUT1.
-19-
button for 2 seconds or
button to set.
psi inHg mmHg
psi
psi
(Positive pressure)
MPa
