Terms
F Fine adjustment mode
Fine adjustment of indicated
value (function)
F.S.
(full span/full scale)
H Hysteresis
I Indication accuracy
Indication light
Indication resolution
Indication unit
Initial setting (mode)
Insulation resistance
K Key lock (function)
M
Manual setup
Max. applied voltage
Max. load current
Measurement mode
Min. setting unit
NPN (open collector) (output)
N
O Operating mode
Output style
P Peak value indication (mode)
PNP (open collector) (output)
Pressure setting
Refer to "Fine adjustment of indicated value".
An indicated pressure value can be adjusted within the range of ±5% R.D.
(±5% of the indicated value). It is used if a true pressure value is known or to
correct the difference of an indicated value of the measurement equipment
nearby that measures the same pressure as the Pressure switch.
Abbreviation for full span and full scale; means the maximum fluctuation range of
the Pressure switch rated value. For example, when the output voltage is 1 to
5[V], the F.S. will be 5-1 = 4[V]. (Reference: 1%F.S. = 4 × 0.01 = 0.04[V])
Difference between the points at which the Pressure switch is turned on and off.
Shows the deviation between displayed pressure value and the true pressure.
The light that turns on when the switch output is on.
How fine the rated pressure range can be segmented. (Example: If a product for 0
to 1 MPa can indicate pressure by 0.001 MPa, the indication resolution is 1/1000.)
The unit of pressure used in the display.
The mode to set the items other than pressure.
Pressure range, display color, operation mode, output format, response time and
auto-preset can be set.
Insulation resistance of a product itself. The resistance between an electric circuit
and a body.
Prohibits a change in the setting of the Pressure switch (locks button operation).
Manual pressure setup without using auto preset. This term is used to
discriminate from the pressure setup using auto preset.
The maximum value of applied voltage available to the output line of the NPN
output.
The maximum current available to the output (output line) of the switch output.
The condition in which the pressure is being detected and indicated and switch
operation is enabled.
Refer to "digit".
The switch that uses the NPN transistor for output.
There are two choices, hysteresis mode and window comparator mode.
The operation theory of the switch output. Either normal output or reversed output
can be selected.
Refer to "List of output mode" on page 20 for the operation status.
Shows the maximum pressure reached at that moment.
The switch that uses the PNP transistor for output.
The setting of pressure to determine the point at which the Pressure switch turns
on and off.
-11-
Meaning
No.PS##-OMH0006-C
