Expobar QUARTZ ONE TOUCH Technical Manual page 63

ExPLODED VIEW
Capsule group Lavazza
Spare parts list
POS. PCS
01 1
02 1
03 1
04 1
05 1
06 1
07 1
08 1
09 1
10 1
11 1
12 1
13 3
14 1
15 1
Part No.
ESC81005 PORTACAPSULES LVZ KIT AUTO-EJECT GROUP
ESC82005 CHAMBER LVZ KIT AUTO-EJECT GROUP
30600009 AUTOMATIC ELBOW RACOR G1/8F - TUBE 4 FKM
50000112 GASKET D7x2 VMQ-70 (RED)
25096510 SCREW PHILIPS 4*8 (DIN 965)
75000015 SHOWER POD D-34
50000063 RETENTION GASKET AUTO-EJECT GROUP LVZ
30210134 RETENTION RING AUTO-EJECT
65000301 SETA VALVE PTFE EMULSIFYING
55000050 SPRING GASKET MUSHROOM TYPE
30370075 STEAM/WATER PIPE ROD
30210170 EXIT EMUL GROUP AUTO-EJECT
25200003 SCREW FOR PLASTIC 3 X 8
C30210081 GROUP LEVER
ESC80005 KIT FOR LVZ CAPSULE AUTOEXP.
QUARTZ
Description
ONE TOUCH
63
