SERVICE PROGRAMMING
Adjusting the capsule storage alarm
Follow the steps below to set the number of capsules required in the box to activate the capsule box alarm:
LANGUAGE
XX
Fig. 01
CAPSULE STORAGE
XX
Fig. 02
Note:
i
By default, the alarm is set to 15 capsules. This setting is adequate for most standard capsules and should
not be adjusted unless a smaller or larger-than-average capsule is selected (capsules must be compatible
with the machine's capsule group) or a waste funnel or an aftermarket, oversized capsule drawer is being
used. Adjusting the setting so that the box is very full of used capsules when the alarm is activated is
not advised, since the box will be difficult to remove and empty, will be very messy, and can cause used
capsules to become jammed inside the machine.
If a waste funnel or an aftermarket, oversized capsule drawer is being used then the alarm can be
deactivated by setting the number to 0 (zero). When deactivating the alarm, it is the responsibility of the
user to make sure that the machine is never blocked/clogged by used capsules.
Adjusting the water filter service alarm
Follow the steps below to set the required number of liters of water cycled to activate the water
filter service alarm:
LANGUAGE
XX
Fig. 03
H2O FILTER
NO
Fig. 04
Note:
i
By default, the alarm is set to NO (turned off). When turned on, the alarm is adjustable from 50 to 500
liters, in 5 liter increments. Adjustment to the number of liters required to activate the alarm should
always take into consideration the cleanliness/quality and pH rating of the local water supply.
30
1. Enter the Service Menu menu (see Fig. 01).
2. Press + until the display shows CAPSULE STORAGE XX (see Fig. 02),
3. Press OK. The current setting will flash. Press
3. When the desired setting is input, press OK to confirm, then press + to
return to the Service Menu.
1. Enter the Service Menu menu (see Fig. 03).
2. Press + until the display shows H2O FILTER NO / XX L (see Fig. 04),
3. Press OK. The current setting will flash. Press
3. When the desired setting is input, press OK to confirm, then press + to
return to the Service Menu.
QUARTZ
ONE TOUCH
or - to adjust it.
+
or - to adjust it.
+
