- Page 1 OFFICE AUTOMATIC OFFICE EB-61 LEVA & BARISTA MINORE PLEASE READ THIS HANDBOOK CAREFULLY BEFORE START UP.
-
Page 2: Identification Of External Components
Identification of External Components WIDE 240 m. HIGH 225 mm DEPTH 420 mm WIDE 240 mm WIDE 260 mm HIGH 225 mm HIGH 225 mm DEPTH 420 mm DEPTH 450 mm Fig. 1 MAIN SWITCH HOT WATER TAP BREWING PUSH BUTTON ELECTRONIC SWITCHBOARD (CONTROL MODEL) BREWING LEVER... -
Page 3: Electrical Installation
Supplied Filter Basket Filter Filter Membrane Coffee Dosage Spoon Spring holder Coffee Tamper 1Cup Filter 2 Cups Filter Basket Basket Fig. 2 Installation • THIS MACHINE IS SUITABLE FOR DOMESTIC USE The machine should be installed on a flat and safe surface. -Electrical Installation: Please observe the following requirements: a) It is necessary to earth the machine. - Page 4 Start-up Steps to follow: 1) If the machine is connected to the water network please open the gate valve (tap at the wall). 2) If the machine is going to work with water tank: Lift the top lid of the coffee machine, remove the water tank. Fill the water tank , do not close the tank until the first coffee comes through.
- Page 5 Filter holder Assembled 2 cups Assembled 1 cup Filter holder Filter holder 1 cup filter 2 cups filter basket basket Fig. 6 Drip tray Removal Remove the grill placed on the drip tray. Lift the tray up slightly at the front, and pull forward to remove it from the machine.
- Page 6 Example of 1 short coffee setting: Take the filter holder from the machine and fill it with the coffee, then place it into the brewing group. Place a cup under the coffee spout and press and hold the “*” button until all the green LEDs on the switch panel light up then immediately press the short coffee.
- Page 7 Water Softener/filter Cleaning a) Fill the water reservoir. b) Dissolve 300 grams of table salt inside the water reservoir. c) Insert the water softener filter inside the water reservoir. d) Siphon the water reservoir through the water softener filter as indicated below. Once the water reservoir is empty, fill it again with non-salt water and repeat the process in order to clean the water softener filter.
- Page 8 Cleaning the Shower Screen and Head Seal After a period (say 6 months in domestic use and weekly cleaning) the shower screen will become clogged with coffee oils that need to be removed. Proceed as follows: • Dislodge the shower screen with its neoprene seal from the group head. This may be accomplished by levering the screen downwards using the handle of a teaspoon.
- Page 9 Filter basket not full. Coffee ground too fine. Remedy: Fill filter basket completely. Coarsen grind. Symptom: Pump lacks pressure. Cause: Poor water supply. Pump defective. Remedy: Call technician. A service to the customers of Expobar (NZ) Ltd 208 Featherston St Palmerston North Phone 06 3593301...
