Expobar QUARTZ ONE TOUCH Technical Manual page 36

CLEANING AND MAINTENANCE
Cleaning of the capsule group
14
The group is now totally disconnected and can be
separated from the machine.
16
Clean the complete capsule group by immerse
it in a container with hot water and professional
cleaning agent. Leave it soaked for around 15
minutes.
Note:
i
Only use professional cleaning
powder for espresso machines.
It's available from your distributor.
Important
:
After cleaning, rinse the capsule group thoroughly
with cool water to ensure all remains of cleaning
agent is removed.
36
15
Disassemble the micro switch by removing the
two screws as shown above.
17
After all necessary parts have been replaced and
before you reassemble the group in the machine,
apply a light coating of grease to the moving parts
and areas shown in yellow the picture to ensure
smooth operation of the group.
i
Part #: 1104162
QUARTZ
Note:
Reassembly of the group should be
performed in reverse order.
Important
:
Once all cleaning and rinsing is complete,
replace all necessary parts according to
the service interval on page 39.
ONE TOUCH
