Expobar QUARTZ ONE TOUCH Technical Manual page 47

ExPLODED VIEW
Water schematic
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
PCS Part No.
1 See Pg. 58-61
See Pg. 58-59,
1
62-63
1 2760068
1 See Pg. 64
1 See Pg. 66-67
1 120620
1 1505042
1 1206123
1 C60100060
1 See Pg. 65
1 1801103
1 See Pg. 56-57
1 See Pg. 70-71
1 See Pg. 68-69
1 See Pg. 54-55
1 C30600009
2 C30600016
- 1505021
- C35021015
- C35021000
- C35021016
1 See Pg. 50-51
1 See Pg. 52-53
1 1860059
1 1660107
Description
Capsule Group Caffitaly
Capsule Group Lavazza
Boiler Assy.
Tank Inlet Valve Assy.
Tank Assy.
Valve Inlet Single 1.8L
Inlet Hose With Connect
Non Return Valve Complete
Flow-Meter
Vibration Pump Assy.
T Connector (4-4-4mm)
Manifold System
Steam Wand Assy.
Water Tap Assy.
Cappuccino Set
Automatic Elbow Racor G1/8F-Tube4
Automatic Straight Racorg1/4F-Tube6
Silicon Hose 10mm (sold in 100cm lengths)
Tube PTFE 4-6 (sold in 100cm lengths)
Tube Silicon 4-7 (sold in 100cm lengths)
Teflon Tube 2*4 (sold in 100cm lengths)
Thermic Assy.
Cappuccino Distributor
Y Connector (4-4-4mm)
Peristaltic Pump
QUARTZ
ONE TOUCH
