ExPLODED VIEW
Machine
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
PCS Part No.
1 261656
2 C50000052
1 2760096
1 C10004180
1 C10004100
1 261655
1 C70001005
1 261654
1 N/A
1 C10004260
1 C20010240
1 C70001002
1 2760201
4 C70000041
1 1264344
1 261652
Description
Side Panel Left
End Gasket d.11
Top Frame Assy.
Cup Tray Stainless Steel
Back Panel
Side Panel Right
Drain Cup
Chassis Base
Chassis Assembly
Capacitive Level Probe Support Sys.
Miniswitch Support Tank Cover Quartz
Threadless Drain Cup
Tube Guide Assy.
Leg-d-30
Tank Divider Panel
Support Panel Electrical
QUARTZ
ONE TOUCH
