USER PROGRAMMING

Advanced cleaning ON/OFF

Follow the steps below to activate or deactivate the machine's semi-automatic milk cleaning system:
DOSE PROGRAMMING
IN 30 SEC.
Fig. 01
ADVANC. CLEANING T1
X s
Fig. 02
Note:
i
If you select YES to activate the Advanced Cleaning function, you must follow the instructions on the
display when the machine reminds you to do the Milk Cleaning starting from the next scheduled cleaning
cycle. Alternatively, if you select NO then the advanced cleaning will be disabled and the system will only
be periodically flushed with hot water, so it is important that you perform the cleaning steps found in the
User Manual at least once per day to ensure the coffee spout and milk system are clean.

Advanced cleaning times - T1, T2, T3, T4

If the advanced cleaning option (shown above) is selected, follow the steps below to program the four
cleaning cycle function pump times: (Each time is programmed separately from within the User Menu.)
DOSE PROGRAMMING
IN 30 SEC.
Fig. 03
ADVANC. CLEANING T1
X s
Fig. 04
ADVANC. CLEANING T2
X s
Fig. 05
ADVANC. CLEANING T3
X s
Fig. 06
ADVANC. CLEANING T4
X s
Fig. 07
22
1. Within the User Menu (see Fig. 01), press
functions until ADVANC. CLEANING YES or NO (See Fig. 02) is shown, then
press OK to enter the menu.
2. Press OK and when the YES or NO option is flashing
deactivate the cleaning function (depending on its current status).
3. Press OK to save your setting then press
1. Within the User Menu (see Fig. 01), press
functions until ADVANC. CLEAN T1 Xs is shown, then press OK to enter
the menu (see Fig. 04).
+ -
2. Press or to set the desired flushing time (between 5 and 20 seconds, the
machine is set to 5 seconds by default).
3. Press OK to save your setting then press
4. After returning to the User Menu, scroll to the ADVANC. CLEAN T2 (see Fig.
05), ADVANC. CLEAN T3 (see Fig. 06), and ADVANC. CLEAN T4 (see Fig. 07)
and repeat steps 2, 3, and 4 to program each pump time configuration.
The pump times correspond to the following cleaning functions:
T1: initial steam cleaning time
T2: milk cleaning solution intake time (5 seconds = approx. 150ml)
T3: hot water from boiler flush time
T4: air intake time, to dry cleaning system
Note:
i
When performed daily, the pump times are recommended to be
set at 5 seconds each.
QUARTZ
-
and to scroll through the menu's
+
-
or to activate or
+
+
to return to the User Menu.
-
and to scroll through the menu's
+
+
to return to the User Menu.
