USER PROGRAMMING

Display functions

EXPOBAR
QUARTZ ONE TOUCH
Greeting message
Boiler temperature
XXX ºC HH:MM
Current time

Machine status

XXX ºC HH:MM
Fig. 01
XXX ºC HH:MM
STANDBY
Fig. 02

Accessing the user menu functions

Follow the steps below to access the machine's User Menu functions:
DOSE PROGRAMMING
IN 30 SEC.
Fig. 03
Enter
Fig. 04
14
Via the machines display you can read or control the following functions:
Adjust automatic daily on/off timer (stand-by).
Adjust clock settings (current time and date).
Change display greeting message.
View the number of coffees dispensed.
View digital boiler-temperature display and control.
Access programming and settings help system.
Reset visual water-softener regeneration alarm.
Change display language.
The machine has three operating statuses:
ON:
The machine is ready for use. This is the normal machine status after turning
on the power switch after the boiler is heated up. (see Fig. 01).
STANDBY:
The power switch is on, but the display shows STANDBY (see Fig. 02). This
means that the machine is in energy-saving mode. To enter this mode, press
OK and the Cappuccino
To exit this mode and turn the machine back on, press the same two buttons
simultaneously again. (They will be flashing already.)
OFF:
The coffee machine is turned off at the main power switch.
Press OK for 5 seconds, or until the button starts to flash and the
display shows DOSE PROGRAMMING, (see Fig. 03), then press OK
again to enter the User Menu.
Within the User Menu, press
and press OK to enter your desired menu option, or press
back (See Fig. 04).
To exit the User Menu, scroll to the end, the display will show
EXIT (See Fig. 05), then press OK. The display will show DOSE
PROGRAMMING (See Fig. 03). Wait 30 seconds and the machine will
return to normal use ON mode.
Scroll forward within the Service Menu
Scroll back within the Service Menu
button simultaneously for at least 5 seconds.
to scroll through the menu's functions
+
QUARTZ
ONE TOUCH
-
to scroll
EXIT
Fig. 05
