Expobar QUARTZ ONE TOUCH Technical Manual page 51

ExPLODED VIEW
Thermic assembly
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
PCS Part No.
1 1264230
1 C30000066
1 C35020001
2 1264231
1 C30000090
4 25091240
1 1264232
1 25091212
1 60000112
1 1860051
4 50000100
1 1364047
1 50010020
1 70000009
1 35010020
2 1264251
2 1860050
2 1264252
2 1860046
2 1860045
2 35021016
1 1264316
Description
O-Ring Dia 44.44*3.5Mm Fkm Fda
Boiler Ring Dia35mm
Thermic Exchanger Dia35mm
O-Ring Dia 28*2.5Mm Fkm Fda
Thermic Main Body D 35
Allen Screw 6*16 Din 912
Isolation Thermic Exchanger
Allen Srew 4*20 Din 912
Electrov. Group Parker 220V
Connector Lg1_8tube Silicon
Viton Electrovalve Gasket
Plug Thermic Exchanger
13.2*18.2*2.5 1/4 Teflon Gasket
Tubular Group Filter
Copper Tube Diam 6*8*126
O-Ring Dia 3.68X1.75mm
Thermic Oring Holder
O-Ring Dia 7.5X1.5mm
Pressure Fitting Tube 4 Conic
Connector G1/4 M Press Conic
Teflon Tube 2*4
Bushing Gasket Teflon
QUARTZ
ONE TOUCH
51
