Expobar QUARTZ ONE TOUCH Technical Manual page 55

ExPLODED VIEW
Cappuccino set
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
PCS Part No.
1 70000034
2 70000033
1 70000035
1 70000031
1 50000117
3 50000100
1 70000032
2 25200003
1 70000061
1 1364082
Description
Front Cappuccino Set
Body Cappuccino Set
Lid Cappuccino Set
Inlet Air & Steam Cappuccino Set
Gasket D7x2.5 Vmq-70
Viton Electrovalve Gasket
Milk Inlet Cappuccino Set
Screw For Plastic 3 X 8
Magnet D10x5
Milk Temperature Regulator M6
