ExPLODED VIEW
Manifold system
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
PCS
Part No.
1
1264253
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
2
N/A
2
N/A
1
60000105
2
C25091211
Description
Distributor Quartz 1Gr
Bypass Closer
Flat Sealing Gasket Nbr 60 Sh Fda (D6x3)
Gasket Seat Of Bypass
Bypass Spring
Setting Screw Of Bypass
O-Ring 7.2 X 1.9 Fkm Green
Catridge Tube 6mm Legris
Shell Tube 6mm
Catridge Tube 4mm Legris
Shell Tube 4mm
Electrov.Base Plate Parker 220V
Allen Screw M4x16 DIN 912
QUARTZ
ONE TOUCH
