Expobar QUARTZ ONE TOUCH Technical Manual page 43

ExPLODED VIEW
Machine front
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12a
12b
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
PCS Part No.
1 1264345
1 1264229
1 1264256
1 1264249
1 1264248
2 C200100220
1 1264343
4 C70000061
1 1264233
1 1264354
1 1264348
1 1264342
1 1264258
1 1660094
1 1264349
1 1264263
1 1660095
1 1264337
1 C30000046
1 6165032
1 1264220
1 1264346
1 70000030
1 C70000027
1 1264350
1 1364085
1 10003126
1 1264347
1 2760311
1 C35021000
Description
Chromed Front Cover
Front Clip Right
Front Clip Left
Chromed Slider Trim Two Spout
Chromed Slider Front Two Spout
Sheetmetal Slides
Front Panel
Magnets
Top Front Cleaning Port Adapto日
Splash Panel
Coffee Spout
Display Trim Panel White
Display Trim Panel Black
Touchpad
Touchpad Cover
Display Cover
Keypad
Group Jet Breaker (One Touch)
Group Jet Breaker (Classic)
Microswitch
Microswitch Housing
Lower Front Cover
Cappuccino Set (One Touch only)
Chromed Handle
Capsule Box
Drip Grill
Drip Tray Float
Drip Tray
Milk System Cleaning Connector w/300mm Sil. Hose
Silicon Milk Inlet Hose Dia. 4*7mm x 600mm
