ExPLODED VIEW
Steam wand
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
PCS
Part No.
2
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
N/A
1
C30370185
1
C35010086
1
C15000339
1
C15000336
1
C40000071
1
C30370132
Description
Tap Shaft Gasket
Tap Closing Disc
Tap Steam/Water Gasket Teflon
Spring Steam/Water Tap
Tap Steam/Water Gasket Brass
O-Ring 12.1X2.7mm
Nut 3/8
Internal Spring (7X146x0,5)
Tube PTFE 4-6
O-Ring 6X1
Steam Tap Nozzle 2H M8.5 With O-ring
Steam Pipe
Steam Wand Assy.
Tap Body Assy.
Steam/Water Tap Knob
Monogrammed Knob
QUARTZ
ONE TOUCH
