C8051F120/1/2/3/4/5/6/7
6.3.

ADC0 Programmable Window Detector

The ADC0 Programmable Window Detector continuously compares the ADC0 output to user-programmed limits,
and notifies the system when an out-of-bound condition is detected. This is especially effective in an interrupt-driven
system, saving code space and CPU bandwidth while delivering faster system response times. The window detector
interrupt flag (AD0WINT in ADC0CN) can also be used in polled mode. The high and low bytes of the reference
words are loaded into the ADC0 Greater-Than and ADC0 Less-Than registers (ADC0GTH, ADC0GTL, ADC0LTH,
and ADC0LTL). Reference comparisons are shown starting on page 80. Notice that the window detector flag can be
asserted when the measured data is inside or outside the user-programmed limits, depending on the programming of
the ADC0GTx and ADC0LTx registers.

Figure 6.12. ADC0GTH: ADC0 Greater-Than Data High Byte Register

0
SFR Page:
0xC5
SFR Address:
R/W R/W
Bit7 Bit6
Bits7-0: High byte of ADC0 Greater-Than Data Word.

Figure 6.13. ADC0GTL: ADC0 Greater-Than Data Low Byte Register

0
SFR Page:
0xC4
SFR Address:
R/W R/W
Bit7 Bit6
Bits7-0: Low byte of ADC0 Greater-Than Data Word.
78
R/W R/W R/W
Bit5 Bit4 Bit3
R/W R/W R/W
Bit5 Bit4 Bit3
Rev. 1.2
R/W R/W R/W
Bit2 Bit1 Bit0
R/W R/W R/W
Bit2 Bit1 Bit0
Reset Value
11111111
Reset Value
11111111
