C8051F120/1/2/3/4/5/6/7
Figure 12.24. EIE2: Extended Interrupt Enable 2
R/W
R/W
-
ES1
Bit7
Bit6
Bit7:
UNUSED. Read = 0b, Write = don't care.
Bit6:
ES1: Enable UART1 Interrupt.
This bit sets the masking of the UART1 interrupt.
0: Disable UART1 interrupts.
1: Enable UART1 interrupts.
Bit5:
UNUSED. Read = 0b, Write = don't care.
Bit4:
EADC2: Enable ADC2 End Of Conversion Interrupt.
This bit sets the masking of the ADC2 End of Conversion interrupt.
0: Disable ADC2 End of Conversion interrupts.
1: Enable ADC2 End of Conversion Interrupts.
Bit3:
EWADC2: Enable Window Comparison ADC2 Interrupt.
This bit sets the masking of ADC2 Window Comparison interrupt.
0: Disable ADC2 Window Comparison Interrupts.
1: Enable ADC2 Window Comparison Interrupts.
Bit2:
ET4: Enable Timer 4 Interrupt
This bit sets the masking of the Timer 4 interrupt.
0: Disable Timer 4 interrupts.
1: Enable Timer 4 interrupts.
Bit1:
EADC0: Enable ADC0 End of Conversion Interrupt.
This bit sets the masking of the ADC0 End of Conversion Interrupt.
0: Disable ADC0 End of Conversion Interrupts.
1: Enable ADC0 End of Conversion Interrupts.
Bit0:
ET3: Enable Timer 3 Interrupt.
This bit sets the masking of the Timer 3 interrupt.
0: Disable Timer 3 interrupts.
1: Enable Timer 3 interrupts.
152
R/W
R/W
R/W
-
EADC2
EWADC2
Bit5
Bit4
Bit3
Rev. 1.2
R/W
R/W
R/W
ET4
EADC0
ET3
Bit2
Bit1
Bit0
SFR Address:
SFR Page:
Reset Value
00000000
0xE7
All Pages
