SMART I/O User's Manual

3.2 Board Overview

From SMART-BASE
or other SMART-EXT
Modules
Page 3 - 4
ST3
SPI
BU1
I/O Slot A
SCRA
©1996 PEP Modular Computers GmbH
Chapter 3 SMART-EXT
SPI
ST5
ST1
MCU
68HC05C4
ST4
ST2
SMART Modules
I/O Slot B
SCRB
To further SMART-EXT
Modules
March 12, 1996
