Introduction
SMART I/O User's Manual

1.4.3 RJ45 Telephone Connector Installation

The RJ45 connector is fitted into the RS232 Telephone connector (BU1) on
the SMART-BASE. This is illustrated in the Figure below.
Figure 1.4.3.1 : RJ45 Telephone Connector Installation
SMART-BASE
SCR2
BU1
RJ45 Connector

1.4.4 Screw Terminal Block Installation

The Screw Terminal Blocks are easily fitted to the SMART-BASE or
SMART-EXT by pushing them onto the relevant Screw Terminal, as shown
in the figure below.
Figure 1.4.4.1 : Screw Terminal Block Installation
March 12, 1996
Page 1 - 16 ©1996 PEP Modular Computers GmbH
