Chapter 5 Analog Modules
D/A Circuit
+15V
-15V
+15V
Jumpers J4 and J5 should be set if the DAC should operate in bipolar mode.
It should be noted that the D/A circuit shown above represents only one of
the two output channels. J5 is naturally the jumper for mode switching on
the second channel.
March 12, 1996
20 k
20 k
J4
20 k
10 V
©1996 PEP Modular Computers GmbH
SMART I/O User's Manual
+15V
20 k
VOUT0
LT1013
1/2
-15V
AGND
5
Page 5 - 15
