SMART I/O User's Manual
Voltage Output Circuit:
DAC
-2.04V reference source
for bipolar operation
Page 5 - 112
Software Controlled
Switch
1/4 DG413
20k
GND
©1996 PEP Modular Computers GmbH
Chapter 5 Analog Modules
1/2 LT112
10V DC
49k9
AGND
October 01, 1996
