SMART I/O User's Manual
Buffer Explanation:
D7
Ch. 7
Bit Value: 0 = No input or not connected

4.4.9 ISaGRAF Programming

4.4.9.1 ISaGRAF Board Parameters
Information on board parameters may be found in the PEP on-
line help and ISaGRAF on-line help or user's manual.
Figure 4-9:
Page 4 - 68 Manual ID 09901, Rev. Index 0500
Ch. 6 Ch. 5 Ch. 4
1 = Input Active
Typical Screen Section for the SM-
ACI1Module
Digital Modules
Ch. 3 Ch. 2 Ch. 1
08 Jan. 98
D0
Ch. 0
