Introduction SMART I/O User's Manual
Screw terminal connectors are available in packs of 5.
1

1.4.2 SMART I/O Module Installation

The SMART I/O Modules are fitted into the relevant sockets (ST1 - ST6; 3
slots) on the SMART-BASE or in sockets on the SMART-EXT unit. It is
important that the Modules are inserted the correct way. The Figure
below illustrates this procedure.
Figure 1.4.2.1 : SMART I/O Module Installation
SMART-Module
SMART-Module
Socket
WARNING!
Once fitted on the board, the Module sockets and components should be on
the right hand side of the Module.
March 12, 1996 ©1996 PEP Modular Computers GmbH Page 1 - 15
