Product
ROM kit v3.x for SMART I/O enables the generation of custom
ISaGRAF-
firmware EPROMs. Platform can be a PC or OS-9 development
ROM-START
system
OS9TRG-RG-
Target CPU kit for SMART I/O (OS-9 v3.x/Ix.x disks)
SMART
OS-9/68000 FasTrak for Windows development pack for SMART I/O.
OS9DEVFT- Contains extended OS-9 v3.x/Ix.x, PEP utilities and I/O drivers with
WIN-SMART necessary makefiles for complete application and EPROM
generation.
OS-9/68000 FasTrak for UNIX development pack for SMART I/O.
OS9DEVFT- Contains extended OS-9 v3.x/Ix.x, PEP utilities and I/O drivers with
UNIX-SMART necessary makefiles for complete application and EPROM
generation.
OS9-PFB- OS-9 PROFIBUS starter kit II for 1 node. Includes license, disk and
SMART manual
OS9-PFB- OS-9 PROFIBUS starter kit II for 1 node operating under FasTrak for
SMART(FT) Windows. Includes license, disk and manual
3 meters with 9-pin D-Sub (female) & RJ45 connectors for PC
Cable
operation
3 meters with 25-pin D-Sub (male) & RJ45 connectors for modem
Cable
operation
Screw Term. For the SMART-BASE timer I/O. Pack of 5, 2x3 array
SCR-2*7. For the SMART-Modules. Pack of 5, 2x7 array
Dummy FP For unused SMART-Module slots. Available in packs of 20
3V, 190mAh lithium batery (button) BR2032 for use in the standard
Battery
temperature range (0 C to +70 C)
3V, 850mAh lithium batery (cylinder) CR14250 for use in the
Battery
extendedtemperature range (-40 C to +85 C)

1.3 Product Information

The SMART-BASE is a control module possessing an RS485 PROFIBUS
and serial RS232 interface as standard and provision for up to three SMART-
Modules. The modules currently available are discussed later. Normally, the
base unit is mounted on a DIN rail (see Weights & Measures section) which
in turn may be fixed in a cabinet. SMART-EXT units may be attached in a
similar manner.
