The two- and three-wire measurement methods shown in figure 5.2.5.2 are
not compensated and will experience errors due to line-resistances. The best
and recommended method is the 4-wire system shown in figure 5.2.5.1.
which eliminates all line resistances automatically. The sense lines, being
connected to a high impedance differential amplifier (10M ), introduce
almost zero error resulting from line-resistances.
Table 5.2.5.2 shows the deviation from the required temperature for both
class A and class B PT100 sensors.
Table 5.2.5.2 Tolerances between Class A and Class B Sensors
Temperature
C
-200
-100
0
100
200
300
400
500
600
650
700
800
850
Driver software running under OS-9 supplies linearization data for use with
DIN standard PT100 sensors. The on-board EEPROM contains board
specific calibration data for self calibration purposes.
Page 5 - 32
Tolerance
Class A
C
0.55 0.24
0.35 0.14
0.15 0.06
0.35 0.13
0.55 0.20
0.75 0.27
0.95 0.33
1.15 0.38
1.35 0.43
1.45 0.46
– –
– –
– –
