Introduction
The attachment of both units is achieved by sliding them over the DIN rail
with the clip assembly pulled out and then releasing it when correctly posi-
tioned.
The 24V supply source should possess the following characteristics:
Because of power limitations, it should be noted that although up to 11
SMART-Modules are possible in a complete configuration, attention should
be paid to the following tables that show the individual component power
requirements. The maximum of 6750mW should not be exceeded as damage
to the on-board DC-DC converter may result due to overheating or entering a
reset status due to the thermal cutoff protection switching mechanism.
Module
SM-DIN1
SM-DOUT1
SM-DAD1
SM-PT100
SM-THERM 400mW
SM-RS232
SM-REL1
March 12, 1996
V o l t a g e
min m a x
18V 36V
S M - B A S E Power Consumption
CPU Core 1500mW
Profibus 250mW
Power Consumption
min m a x
5mW 100mW
5mW 270mW
350mW 450mW
400mW 500mW
500mW
23mW 75mW
23mW 160mW
©1996 PEP Modular Computers GmbH
SMART I/O User's Manual
Current
Continuous P e a k
400mA 1.5A (2ms)
min m a x
1700mW
750mW
Module Power Consumption
min
SM-ADC1 350mW
SM-DAC1 5mW
SM-DAC1 350mW
SM-SSI unknown
m a x
450mW
400mW
660mW
unknown
Page 1 - 11
