1.2 Ordering Information

Product
SMART-BASE
SMART-BASE
SMART-EXT
SM-DIN1
SM-DOUT1
SM-DAD1
SM-PT100
SM-THERM
SM-REL1
SM-RS232
SM-SSI
SM-ADC1
SM-ADC1
SM-DAC1
SM-DAC1
SM-DAC1
SM-DAC1
All SM-Modules are delivered without screw terminals.
March 12, 1996
Micro PLC & real-time computer, 1 MByte EPROM, 512 kByte DRAM,
64kByte SRAM, OS-9 v3.0, ISaGRAF v3.0x, PROFIBUS v3.12, Layer
2 & 7, RTC, full modem RS232 (8-pin RJ45 connector), 190 mAh
battery, housing and terminal block for the 24V DC power supply
As product 13843 but with additional 1 MByte Flash memory (TSOP) on
solder side
Expansion module for the SMART-BASE supporting 2 SMART-Modules
Delivered without terminal blocks, SMART-Modules or blank panels
SMART-Module with 8 optoisolated 24V DC digital inputs
SMART-Module with 8 optoisolated 24V DC/500mA digital outputs
SMART-Module with 4 channel A/D ( 10V), 2 channel D/A ( 10V, 0..10V) 9868
SMART-Module with 4 optoisolated 2, 3 or 4-wire PT100 inputs
SMART-Module with 4 optoisolated thermocouple inputs
SMART-Module with 6 optoisolated normally open relay outputs
SMART-Module with RS232 (Rx & Tx) interface
SMART-Module with 1 SSI channel providing a 24V DC digital input and a
24V DC, 500mA digital output
SMART-Module with 6 12-bit, 10V optoisolated analog inputs
SMART-Module with 6 12-bit, 0..20mA optoisolated analog inputs
SMART-Module with 2 12-bit, 10V optoisolated analog outputs
SMART-Module with 2 12-bit, 0..20mA optoisolated analog outputs with
current sensing for broken sensor detection
SMART-Module with 6 12-bit, 10V optoisolated analog outputs
SMART-Module with 6 12-bit, 0..20mA optoisolated analog outputs with
current sensing for broken sensor detection
©1996 PEP Modular Computers GmbH
SMART I/O User's Manual
Description
1
Order Nr.
13843
13844
4228
4229
4231
12405
12426
12238
12461
12825
13380
13868
13379
14018
14019
14020
