Total Access 5000 Business Services Deployment Guide

Access the T1 8-Port Line Module

To access the T1 8‐Port Line Module, complete the following:
1. From the Total Access 5000 Main menu, select Module Menus , and press E
2. From the Module Menus menu, select T1 8‐Port, and press E

Provision the T1 8-Port Line Module Service State

The card service state must be set to IS or OOS‐MA.
NOTE
If the card service state is set to OOS‐MA, normal operation occurs but alarms
are not reported.
To set the card service state, perform the following procedure:
1. From the T1 8‐Port Line Module menu, select Provisioning , and press E
2. From the Provisioning menu, select Card Service State , and press E
3. From the Card Service State menu, select the appropriate service state, and press E

Provision the T1 8-Port Line Module DS1 Interface Service State

For each DS1 port being used, the service state must be set to IS.
To set the DS1 port service state, perform the following procedure:
1. From the Provisioning menu, select DS1 Port Interfaces , and press E
2. From the DS1 Port Provisioning menu, select Service State , and press E
3. From the Service State menu, select the service state of the DS1 Port, and press E

Provision the Timing Source

To provision the T1 8‐Port timing source, complete the following:
1. From the Provisioning menu, select EFM Setting , and press E
2. From the EFM Settings menu, select Timing , and press E
3. From the Timing menu, select LoopA Timing Source , and press E
4. From the LoopA Timing Source menu, select the required option, and press Enter.
5. From the Timing menu, select LoopB Timing Source , and press E
6. From the LoopB Timing Source menu, select the required option, and press Enter.
J-8
This menu contains the following options:
• Select DS1: This setting allows the entry of the DS1 timing source. The valid settings
are from 1–8.
• None: When selected, this option does not set the timing source to the DS1. Timing
defaults to the timing set in the GigE SM.
This menu contains the following options:
• Select DS1: This setting allows the entry of the DS1 timing source. The valid settings
are from 1–8.
NTER .
NTER .
NTER .
.
NTER
NTER .
.
NTER
NTER .
NTER .
.
NTER
.
NTER
65K510DEP08-1A
