TSU NetVanta Router Module
(with ADTRAN OS Command Line Interface)
Quick Start Guide
Before you begin...
Tools Required
•
A VT100 terminal or a PC with VT100 emulator software for connecting to the unit.
The configuration sections of this quick start guide are formatted to provide both step-by-step text
descriptions and screen shots containing a text script. The configuration scripts are available on the
TSU NetVanta Router Module Documentation CD.
Specifications
Interface Type:
10/100 BaseT (RJ-48)
Configuration:
Mapping and testing functions performed through TSU/ESU front panel.
All router configuration performed through the CONTROL interface using ADTRAN OS Command Line Interface.
Environmental Specifications:
Operating Temperature: 0°C to 45°C
Storage Temperature: -20°C to 70°C
Relative Humidity: Up to 95% non-condensing
Network Diagrams
Point-to-Point T1 Diagram (Use Steps 1-4, 6-12 to configure the PPP example and 1-5, 7-12 to
configure the Frame Relay example.)
Branch Office
eth 0/1
LAN IP: 10.10.20.7/24
When designing a point-to-point application, ensure that there is timing on the circuit (by setting one unit
to internal timing and one to network recovered timing). In addition, point-to-point frame relay
applications require one device configured for USER signaling and one for NETWORK signaling.
TSU
Point-to-Point T1
TSU IQ
A
B
C
ENTER
1
2
3
D
E
F
4
5
6
NEXT
PREV
ADD
7
8
9
SHIFT
DELETE
QUICK
CANCEL
*
0
#
FR 1
or
DLCI 16
Annex D Signaling
192.22.72.1/24
61202350L1-13A
Compliance:
FCC Part 15, Class A
UL 60950, 3rd Edition
EN 60950
ETSI 300 386
V.35
TSU
ENTER
CANCEL
PPP1
PPP Signaling
RIP V2
192.22.72.1/24
1
Corporate HQ
LAN IP: 190.72.22.40/24
TSU IQ
A
B
C
1
2
3
D
E
F
4
5
6
NEXT
PREV
ADD
7
8
9
SHIFT
DELETE
QUICK
*
0
#
Router
Gateway Router
192.22.72.101/24
June 2003
