B
LUESOCKET V
P/N 1700918F1
G
S
ETTING
TARTED
The ADTRAN Bluesocket virtual wireless local area network (vWLAN) is a secure wireless
solution composed of the vWLAN desktop appliance and associated Bluesocket access points
(BSAPs). The vWLAN desktop appliance runs vWLAN software and is configured by installing
the desktop appliance and associated BSAPs. This document describes the initial setup of the
vWLAN desktop appliance for use with vWLAN.
ADTRAN PART NUMBER: 1700918F1
DC 12V
5A
Power Plug
The Bluesocket vWLAN Desktop Appliance (P/N 1700918F1) only functions with
vWLAN software release 2.5 or later. This desktop appliance should never be
downgraded to a software version prior to vWLAN 2.5.
Quick Start Guide, 61700918F1-13A, January 2015
WLAN D
RISK OF
ELECTRICAL SHOCK
DO NOT OPEN
WARNING
Power off when connecting live devices.
VGA Port
This product contains hazardous moving parts. Keep away from fan blades
when servicing this unit.
A
ESKTOP
PPLIANCE
NTWK
MGMT
Tested to comply with FCC standard.
For home or office use.
Public
Private
Port
Port
Power Button
CONSOLE
9-pin Serial Port
1
