ADTRAN 1442401G1 Quick Start Manual

10G, 850 nm Multi-mode Fiber, Limiting, SFP+
CLEI: BVL3AHZD_ _
Product P/N: 1442401G1
D
ESCRIPTION
The Small Form-Factor Pluggable 10 Gigabit Multi-Mode
Limiting SFP+ (MMF SFP+) optical transceiver is a fully duplex
serial electric, serial optical device with both transmit and receive
functions contained in a single module that provides a high speed
serial link at 10 Gbs. Installed into an appropriate host module,
the MMF SFP+ provides a 10 Gigabit interface to the supporting
system.
The transmit side of the SFP+ converts serial NRZ electrical data
at the 10 Gbs line rate to a standard compliant optical signal. The
receive side of the SFP+ converts the incoming DC balanced serial
NRZ optical data at the 10 Gbs line rate into serial electrical data.
The following features are supported on the SFP+:

850 nm optical signals for up to 300 meters reach

Case temperature hardened range from –40°C to 85°C

Low power consumption (<1 W max)
 -12
Bit error rate (<1x10 )

Excellent EMI performance
!
CAUTION
Due to compliance certification requirements, only SFP+s
supplied by ADTRAN are to be used with the host module.
ADTRAN cannot certify system integrity with other SFP+s.
Total Access 5000
Small Form-Factor Pluggable,
Operational Specifications

Optical Specifications:
o 850 nm optical signals for up to 300 m reach
o Data rate: 9.95 to 10.5 Gbs
o
Optical transmit level: –5.0 to –1.0 dBm
o
Optical receive level sensitivity: –11.1 dBm (+0.5)
o Optical distance: 300 meter maximum
o Optical connectors: LC

Extended Environmental Support:
o
Operational temperature range: –40°C to +85°C
o
Storage temperature range: –40°C to +85°C
o Relative humidity to 85%, noncondensing
I
NSTALLATION
Before installing the equipment, inspect the SFP+. If damage has
occurred during shipping, file a claim with the carrier, and then
contact ADTRAN Customer Support. For more information, refer
to the warranty.
To install the SFP+ into an appropriate module, complete the
following steps:
NOTE
Do not remove the protective end cap from the SFP+ until the
fiber optic cable is ready to be connected.
1. Insert the SFP+ into the cage on the module. Ensuring that
the latch handle on the SFP+ is facing upward, slide the
SFP+ all the way into the SFP+ cage until there is an audible
"click".
NOTE
The latch on the SFP+ is for removal only. When removing the
SFP+, rotate the latch away from the SFP+, the SFP+ should easily
slide out of the cage.
2. Do not remove the protective end cap until the optical fiber
connection is made.
NOTICE
It is recommended that the protective end cap remain on
whenever the transceiver optical fiber connector is not inserted.
3. Continue the installation and turn-up of the host module
using the instructions in the Job Aid provided with the
module or other system-level documentation available
online at www.adtran.com.
jobAid
Issue Date: April 2013
Document P/N: 61442401G1-22B
