Total Access 5000 Business Services Deployment Guide

Provision LACP

When connecting the GigE SM to the provider network interface element (normally a switch
or a router), multiple configuration options can be used. The current BSM application
connects to the external switch with a single Switch Module port (NET 1) from each Switch
Module, using Link Aggregation Control Protocol (LACP) to convey Active/Standby status of
each GigE SM port.
NOTE
The maximum data rate for the network interface is still 1 Gbps. The use of
LACP is independent of using link aggregation to obtain greater than 1 Gbps
network connection. This LACP use is often called hot‐standby LACP.
Table 3‐5 displays the three LACP modes.
Command
lacp mode active
lacp mode passive
no lacp mode
To provision for LACP, complete the following procedure:
1. From the Enable prompt, type configure terminal , and press E
2. From the Global Configuration prompt, type interface gigabit-ethernet 1/A/1 ,
NOTE
If slot B is the active SM, use 1/B/1 for the <shelf/slot/port> syntax.
3. Provision the LACP Mode by performing one of the following commands:
3-12
bal Configuration prompt.
and press E
NTER to access the GigE SM in slot A and the Net 1 Configuration prompt.
• Type lacp mode active , and press E
• Type lacp mode passive , and press E
• Type no lacp mode , and press E

Table 3-5. LACP Modes

Description
The GigE SM always sends LACP packets along the configured links.
The GigE SM will not send LACP packets until it has first received an
LACP packet.
LACP is disabled for this port.
NTER to set the port LACP mode to active
NTER
to set the port LACP mode to disabled
NTER
NTER to access the Glo‐
to set the port LACP mode to passive
65K510DEP08-1A
