■ Mounting

Select a location that provides easy access to the con-

troller for navigation safety, has good ventilation and is

not subject to sea spray. The controller should be at 90

degrees to your line of sight when operating it.

D Mounting the controller/speaker/main unit

CONNECTION AND INSTALLATION

CAUTION: KEEP the transceiver and microphone

at least 1 meter away from your ship's magnetic

navigation compass.

Check the installation angle; the display may not be

easy to read at some angles.

R WARNING! NEVER

main unit overhead. The weight of the unit is

approximately 4.7 kg (10 lb 6 oz), but its apparent

weight will increase several fold due to wave

shocks or vibration. The unit must be mounted on

a flat hard surface only.

mount the transceiver
