■ Memory description

The IC-M802 has several kinds of memories as fol-
lows:
• Address and group ID code memories (p. 46)
• Call, traffic and scan frequency memories. (p. 47)
• DSC transmission memory (described in this section)
• Received message memory (p. 40)

■ Memory writing

q During DSC watch mode, select the desired for-
mat category (except distress and test), and set
the message, traffic and call frequencies until the
call stand-by screen is displayed as described in
the CALL PROCEDURE section (pp. 21–37).
w Hold down [ENT] for 1 second to select the TX
memory write mode.
e Rotate [CH] to select the desired memory channel.
- - - T X m e m o r y w r i t e - - - -
0 :
Ç
1 :
2 :
3 :
4 :
5 :
S E L W r i t e

■ Memory reading/transmitting/deleting

q Push [DSC] to select DSC watch mode, if neces-
sary.
w Push [TX ] to enter the DSC transmit memory
txf
screen.
• Or, push [MODE
set
memory" then push [ENT], also selects the transmit
memory screen.
e Rotate [CH] to select the selected memory chan-
nel to be read.
* * * * * * T X m e m o r y * * * * * * *
- - - - - - - - S e l e c t - - - - - - - -
0 : I n d i v i d u a l 9 8 7 6 5 4 3 2 1
Ç
1 :
2 :
3 :
4 :
5 :
S E L O K
], rotate [CH] to select "TX

MEMORY OPERATION

10 DSC transmission memory channels allow you to
set often used format specifiers and contents such as
for routine calls, group calls, etc.
r Hold down [ENT] for 1 second again to store the
condition into the selected memory channel.
• The set DSC format and calling station ID/name ap-
pear.
- - - T X m e m o r y w r i t e - - - -
0 : I n d i v i d u a l 9 8 7 6 5 4 3 2 1
Ç
1 :
2 :
3 :
4 :
5 :
S E L
t Push [ENT] to return to the calling stand-by condi-
tion, or push [MODE
mode.
r Push [ENT] to display the memory contents.
* * * * * * T X m e m o r y * * * * * * *
- - - - - - I n d i v i d u a l - - - - - -
C a t e g o r y : D i s t r e s s
T o : 9 8 7 6 5 4 3 2 1
T r a f f i c : R a d i o t e l e p h o n e
T X
R X
C a l l F r e q : T X
C a l l
t Operate as follows:
➥ When reading the memory contents only;
• Push [MODE
mode.
➥ When transmitting the memory contents;
• Hold down [CANCEL/CALL] for 1 second.
➥ When clearing the memory contents;
• Hold down [CE] for 1 second.
9
O K
] to return to DSC watch
set
2 1 3 4 . 0 k H z
2 1 3 4 . 0 k H z
2 1 8 7 . 5 k H z
R X 2 1 8 7 . 5 k H z
D E L
] to return to DSC watch
set
8
9
45
