■ Supplied Accessories

Microphone
Microphone hanger
and screw set
DC power cable Function name
stickers*
Mounting bracket Flat washers
Spring washers
Nuts
1
*
Used for labelling the programmable
function keys according
assinged functions.
2
*
Used for the optional unit installation.
Ask your dealer for details.
Microphone
hanger cable
2
Sponges*
1
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
to their
CONNECTION AND MAINTENANCE

■ Mounting the transceiver

The universal mounting bracket supplied with your trans-
ceiver allows overhead mounting.
• Mount the transceiver securely with the 4 supplied screws
to a thick surface which can support more than 1.5 kg.
Nut
Flat washer
Felt*
Spring washer
Felt*
When using
*Felts reduce the vibration effects.
self-tapping screws
