Specifications - Icom IC-M802 Instruction Manual

• General
• Frequency coverage :
Receive 0.5–29.9999
Transmit 1.6–2.9999
6.0–6.9999
12.0–13.9999
18.0–19.9999
25.0–27.5000
• DSC channels : 2,187.5 kHz, 4,207.5 kHz,
6,312.0 kHz, 8,414.5 kHz,
12,577.0 kHz, 16,804.5 kHz
• Type of emission :
Transceiver J3E
F1B
DSC receiver J2B
• Number of memory Channels:
1355 channels (maximum)
160 user programmable, 249
ITU SSB duplex, 124 ITU SSB
simplex, 662 ITU FSK duplex and
160 e-mail channels
: SO-239×2 (50 Ω)
• Antenna connector
• Usable temperature range : –30˚C to +60˚C ; –22˚F to +140˚F
(Specifications guaranteed –20˚C to +55˚C range only.)
• Frequency stability (–20˚C to +55˚C):
Transceiver ±10 Hz
DSC receiver ±10 Hz
(Approximately 5 minutes after battery connection)
• Power supply : 13.6 V DC ±15%
• Current drain :
Transmit at maximum power 30 A typical
Receive at maximum audio 3.0 A
• Dimensions
(projections not included)
Main unit 240(W)×94(H)×238.4(D) mm
; 9.4(W)×3.7(H)×9.4(D) in
Controller (RC-25) 220(W)×110(H)×84.4(D) mm
; 8.7(W)×4.3(H)×3.3(D) in
Speaker (SP-24) 110(W)×110(H)×84.4(D) mm
; 4.3(W)×4.3(H)×3.3(D) in
• Weight (approximately) :
Main unit 4.7 kg; 10 lb 6 oz
Controller (RC-25) 570 g; 1 lb 4 oz
Speaker (SP-24) 370 g; 13 oz
• Accessary connector : 8-pin DIN connector
• CONTROLLER connector : 8-pin MINI DIN connector
• GPS connector : BNC connector
( NMEA0183 ver. 3.01, sentence
formatter: GGA)
• REMOTE connector : D-sub 9-pin (RS-232C/NMEA)
• AF/MOD connector : D-sub 9-pin
(Unit: MHz)
4.0–4.9999
8.0–8.9999
16.0–17.9999
22.0–22.9999
, H3E,* J2B
(USB/LSB) (AFSK)
, A1A
(FSK) (CW)
*Receive only
(negative ground)
:

SPECIFICATIONS

• Transmitter
• Output power
1.6–27.5000 MHz
• Spurious emission
• Carrier suppression
• Unwanted sideband
suppression
• Microphone connector : 8-pin connector (2.4 kΩ)
• Receiver
• Sensitivity
Transceiver
J3E, A1A
,
(20 dB SINAD)
J2B, F1B
(20 dB SINAD)
H3E
(20 dB SINAD)
DSC receiver
• Spurious response rejection ratio:
Transceiver
DSC receiver
• AF output power
(at 13.6 V DC)
• CLARITY variable range : ±150 Hz
• Headphone connector : 3-conductor 3.5 (d) mm (0.1")
• SP connector
All stated specifications are typical and subject to change without no-
tice or obligation.
14
:
150/60/20 W p–p
: –62 dB
: 40 dB below peak output power
: 55 dB below peak output power
:
30 dBµV emf
(0.5–1.5999 MHz)
13 dBµV emf
(1.6–1.7999 MHz)
8 dBµV emf
(1.8–29.9999 MHz)
13 dBµV emf
(1.6–1.7999 MHz)
8 dBµV emf
(1.8–29.9999 MHz)
44 dBµV emf
(0.5–1.5999 MHz)
30 dBµV emf
(1.6–1.7999 MHz)
24 dBµV emf
(1.8–3.9999 MHz)
0 dBµV emf
(all channels)
More than 70 dB
(0.5–29.9999 MHz)
More than 60 dB (1st image)
More than 50 dB (except 1st image)
: More than 4.0 W at 10% distortion
with a 4 Ω load
: 2-conductor 3.5 (d) mm (0.1")/4 Ω
