12
CONNECTIONS AND MAINTENANCE
■ Mounting the transceiver
The universal mounting bracket supplied with your
transceiverenablesoverheadorflatmounting.
• M ount the transceiver securely with the 5 supplied (M5 × 20)
screws to a surface that is more than 10 mm thick and can
support more than 5 kg.
• M ountthetransceiversoitsfaceisat90°toyourlineof
sight when operating.
CAUTION: Keep the transceiver and microphone at least
1 meter (3.3 feet) away from your vessel's magnetic
navigation compass.
NOTE:
• C hecktheinstallationangle.Thefunctiondisplaymaynot
be easy to read at some angles.
• W hen mounting the transceiver on the place that is prone
to strong vibration, use the supplied sponges between the
transceiver and mounting bracket to reduce the vibration.
98
*
Sponges reduce the vibration effects.
See NOTE shown to the left.
Sponge*
