Copy Operations
– When the "Corner" Staple setting is selected.
– Touch [Auto] to automatically determine the stapling position according to the orientation of the
loaded document. If the document length is 297 mm or less, the long side of the paper is stapled.
If the document length is more than 297 mm, the short side of the paper is stapled.
– If "Auto" is selected for the stapling position, load the document with the top toward the back of the
machine. If the document is loaded in any other orientation, the stapling will not be correctly
positioned.
– If "Auto" is selected, the stapling position is set at the top or at the left.
– To cancel the setting and select the default, press the [Reset] key.
4
If desired, touch [Original Direction], and then select the setting appropriate for the document.
5
Touch [OK].
The Basic screen appears again.

Punching holes in copies ("Punch" settings)

!
Detail
In order for holes to be punched in the copies, all of the following conditions must be met.
The paper width must be between 280 mm and 297 mm.
The paper length must be between 182 mm and 432 mm.
If a Punch setting is to be selected, select the orientation in which the document is positioned. If an
Original Direction setting is not selected, holes may not be punched in the copies as desired.
Note
The Punch settings are available only if the punch kit is installed on the optional finisher.
When Punch kit PK-512 and/or Finisher FS-517/FS-608 are installed
Tray
Finishing Tray 1
When Punch kit PK-513 and/or Finisher FS-517/FS-608 are installed
Tray
Finishing Tray 1
ineo+ 650/550/451
Paper weight
2 2
64 g/m to 128 g/m
Paper weight
2 2
64 g/m to 128 g/m
Paper size
"4-Hole" Punch setting:
A3 w, B4 w, A4 v, B5 v, 11 e 17 w, 8-1/2 e 11 v,
7-1/4 e 10-1/2 v, 8K w, 16K v
Paper size
"4-Hole" Punch setting: A3 w, B4 w, A4 v, B5 v
2
