Editing An Overlay File; Creating An Overlay File - Develop ineo+ 451 User Manual

Print Operations

Editing an overlay file

To use an overlay, an overlay file must be created and added to the overlay file list. You can create and save
a new overlay file by selecting the "Create Overlay File" check box, specifying the document that you want
to create as an overlay file, then clicking the [Print] button on the Print dialog box. To add an existing overlay
file that was created to the list, specify the file.

Creating an overlay file

1
Create the overlay file data using any application.
2
From the [File] menu, select "Print".
3
Select this machine in "Printer Name", and then click the [Properties] button or the [Preferences] button.
4
Click the Stamp/Composition tab.
5
Select the "Create Overlay File" check box.
6
Click the [OK] button.
The Print dialog box appears again.
7
Click the [Print] button.
The dialog box to save the overlay file appears.
ineo+ 650/550/451
3
3-25
