Web Connection Operations
If "Abbr. Dial" was selected
Note
"Abbr. Dial" appears if the optional fax kit has been installed.
Item
No.
Name
Index
Limiting Access to Destinations
Destination
Line Setting
Communication Setting
If "IP Address Fax" was selected
Note
"IP Address Fax" appears if the IP address fax operation is available.
Item
No.
Name
Index
Limiting Access to Destinations
Host Address
Port No.
Destination Machine Type
ineo+ 650/550/451
Description
Specify the registration number.
Select "Use opening number" or "Direct Input". If "Direct Input" is selected, type in
the number. If "0" is specified, the user box is automatically registered with the next
available number.
Type in the name of the destination (up to 24 characters).
Select the index characters for the destination. To normally display the destination
in the touch panel, check the "Main" check box.
Select the display level for the destination.
If "Search from Reference Allowed Group" is selected, click the [Search from List]
button, and then select an access permission group from the list. If "Set direct Ref-
erence Allowed Level" is selected, select a level.
Type in the fax number for the destination (up to 38 characters, including only nu-
merals, #, *, -, T, P and E).
Select the line to be used ("No Selection", "Line 1" or "Line 2"). A setting can be
selected if the optional fax multi line is installed.
Click the [Display] button, and then select the check box for a displayed setting
("V34 off", "ECM Off", "International Communication" or "Check Destination").
Description
Specify the registration number.
Select "Use opening number" or "Direct Input". If "Direct Input" is selected, type in
the number. If "0" is specified, the user box is automatically registered with the next
available number.
Type in the name of the destination (up to 24 characters).
Select the index characters for the destination. To normally display the destination
in the touch panel, check the "Main" check box.
Select the display level for the destination.
If "Search from Reference Allowed Group" is selected, click the [Search from List]
button, and then select an access permission group from the list. If "Set direct Ref-
erence Allowed Level" is selected, select a level.
Type in the IP address or host name for the destination fax (up to 63 characters).
To type in the host name, check the "Please check to enter host name." check box.
If the machine is set to use IPv6, an IPv6 address can also be specified.
Type in the port number. (Range: 1 to 65535; Default: 25)
Select whether the destination is a color or monochrome machine.
