8.5.14. Lock an output

Command format
CALL/MEDIA/VIDEO/XP:lockDestination(<O
Response format
mO/MEDIA/VIDEO/XP:lockDestination
Example
> CALL/MEDIA/VIDEO/XP:lockDestination(O1)
< mO/MEDIA/VIDEO/XP:lockDestination

8.5.15. Unlock an output

Command format
CALL/MEDIA/VIDEO/XP:unlockDestination(<O
Response format
mO/MEDIA/VIDEO/XP:unlockDestination
Example
> CALL/MEDIA/VIDEO/XP:unlockDestination(O1)
< mO/MEDIA/VIDEO/XP:unlockDestination

8.5.16. HDCP setting (input port)

HDCP capability can be enabled/disabled on the input ports, thus, non-encrypted content
can be seen on a non-HDCP compliant display. See more information in section
page 16.
Command format
SET/MEDIA/VIDEO/<In>.HdcpEnable=true|false
Response format
pw/MEDIA/VIDEO/<In>.HdcpEnable=true|false
Example
> SET/MEDIA/VIDEO/I1.HdcpEnable=false
< pw/MEDIA/VIDEO/I1.HdcpEnable=false

8.5.17. HDCP setting (output port)

HDCP capability can be set to Auto/Always on the output ports, thus, non-encrypted
content can be transmitted to a non-HDCP compliant display. See more information in
section
Command format
SET/MEDIA/VIDEO/<On>.HdcpModeSetting=0|1
Response format
pw/MEDIA/VIDEO/<On>.HdcpModeSetting=0|1
Parameters
Example
> SET/MEDIA/VIDEO/O1.HdcpModeSetting=0
< pw/MEDIA/VIDEO/O1.HdcpModeSetting=0
Section 8. LW3 Programmers' reference
3.4 on page 16.
.HdcpModeSetting
HDCP mode
>)
n
>)
n
0 1
Auto Always
MMX6x2-HT
User's Manual
3.4 on
Page 91 / 119
