6.6.6. Deleting EDID(s)

The EDID(s) from User memory can be deleted as follows:
Step 1. Press User button on the top of the Destination panel.
Step 2. Select the desired memory slot(s); one or more can be selected ("Select All" and
Step 3. Press the Clear selected button to delete the EDID(s).

6.6.7. EDID Summary window

Select an EDID from the Source panel and press the Info button to display the EDID
summary.

6.6.8. Editing an EDID

Select an EDID from Source panel and press the Edit button to display Advanced EDID
Editor window. The editor can read and write all descriptors, which are defined in the
standards, including the additional CEA extensions. Any EDID from the device's memory
can be loaded into the editor. The software resolves the raw EDID and displays it as
readable information to the user. The modified EDID can be saved to the User memory.
Section 6. Software control – Using Lightware Device Controller
"Select None" buttons can be used). The EDID(s) will be highlighted with a yellow
cursor.
Figure 6-9. Advanced EDID Editor
Figure 6-8. EDID Summary
