6.8.4. Clear one or more Event(s)

Clear an Event
Press the Clear button in the Event list or in the header section in the Event editor.
Clear all Events
When all the Events must be cleared press the Load factory defaults button above the Event
list. You will be prompted to confirm the process.

6.8.5. Export and import the Events

The feature allows saving all the Events. The backup file can be uploaded to another
MMX6x2-HT matrix.
Export all the Events
Step 1. Press the Export button above the Event list.
Step 2. The Save as dialog box will appear. Set the desired folder and file name, then press
The generated file is a simple text file which contains LW3 protocol commands. The file
can be viewed by a simple text editor, e.g. Notepad.
ATTENTION!
Editing the file is recommended only for expert users.
Import all the Events
Step 1. Press the Import button above the Event list.
Step 2. The Open dialog box will appear. Select the desired folder and file, then press the

6.9. Settings menu

6.9.1. Status tab

General information is shown on this tab, such as device label, part number, serial number
and hardware health, voltage and temperature values.
Page 62 / 119
the Save button.
Open button.
Section 6. Software control – Using Lightware Device Controller
Figure 6-16. Status tab
