7.3.3. Unmute specified output

Description: Unmute output <out>.
Command {+<out>}
Response (0MT<out²>)CrLf
Explanation: O1 port is unmuted.
INFO
Unmuting an output makes the previous connection active as the crosspoint's state has not
been changed with the muting command, only the output was disabled.

7.3.4. Lock the output

Description: Lock output <out>. Output's state cannot be changed until unlocking.
Command {#><out>}
Response (1LO<out²>)CrLf
Explanation: O1 port is locked.

7.3.5. Unlock the output

Description: Unlock output <out>. The connection on output can be changed.
Command {+<<out>}
Response (0LO<out²>)CrLf
Explanation: Output 1 is unlocked.
INFO
The device issues the above response regardless of the previous state of the output (either
it was locked or unlocked).

7.3.6. View connection state on the output

Description: Viewing the output's connection results in different response length, because
it depends on the device. The response below refers to an MMX6x2-HT220.
Command {VC}
Response (ALL●<O1>●<O2>●<O3>●
Legend: All <Ox> indexes show the corresponding output's connection state. If value
<O1> equals 03 it means that output 1 is connected to input 3. All <Ox> indexes are two
digit ASCII characters (01, 02, 04, etc.).
State letters
Explanation: I3 is switched to O1 and O3. I4 is switched to O2 and O4.
INFO
As the output ports are mirrored O1 and O3 transmit the same input, such as O2 and O4.
Page 70 / 119
Format
Format
Format
Format
<O4>)CrLf
Letter
L
M
U Output is locked and muted
Example
→ {+01}
← (0MT01)CrLf
Example
→ {#>01}
← (1LO01)CrLf
Example
→ {+<01}
← (0LO01)CrLf
Example
→ {vc}
← (ALL 03 04 03 04)CrLf
State
Output is locked
Output is muted
Section 7. LW2 programmers' reference
Example
L01
M01
U01
