2.3.4. TPS input/output ports

The matrix provides standard RJ45 connectors for TPS input and output ports.
The recommended termination is based on TIA/EIA T 568 A or TIA/EIA T 568 B standards.
Pin
1
2
3
4
5
6
7
8
When a standard Ethernet device is connected to the TPS connector for some reason, the
port is switched to Ethernet fallback mode automatically.

2.3.5. LAN and TPS Ethernet port

The matrix contains two RJ-45 connectors for Ethernet/LAN connection: one for local
control functions and one for the TPS lines. The two interfaces are connected (default) but
can be separated. The connector with "LAN" display is for local controlling functions – the
matrix can be configured and controlled via local Ethernet via this port. The connector with
"TPS Ethernet" display is to supply the Ethernet to the TPS ports.
The Ethernet ports can be connected to a LAN hub, switch or router by a CATx cable.
However both cable types (straight or cross) are supported and handled by the device,
below pin assignment is recommended.
OFF
Blink
ON
Page 14 / 119
RJ45 receptacle
TIA/EIA T568 A color and name
white/green stripe
white/orange stripe
white/blue stripe
orange solid
white/brown stripe
LED1 (green) LED2 (yellow)
10 Mbit/s not linked
- activity
100 Mbit/s no activity
Figure 2-3. RJ45 connector and pin assignments for Ethernet
RJ45 plug
TIA/EIA T568 B
green solid
blue solid
brown solid
Pin no.
1
2
3
4
5
6
7
8
Section 2. Controls and connections
color and name
white/orange stripe
orange solid
white/green stripe
blue solid
white/blue stripe
green solid
white/brown stripe
brown solid
Name Wire color
TX + Green stripe
TX - Green
RX + Orange stripe
Not used Blue
Not used Blue stripe
Rx - Orange
Not used Brown stripe
Not used Brown
