1. If you have not already done so, connect a terminal or a terminal emulator (PC or
workstation) to the SC serial management port. Configure the terminal or terminal
emulator with these settings:
9600 baud
■
8 bits
■
No parity
■
1 Stop bit
■
No handshaking
■
Note – When you power on the server for the first time and you do not have a
terminal or terminal emulator (PC or workstation) connected to the SC serial
management port, you will not see system messages. The display times out and
disappears after about 60 seconds.
2. Turn on the terminal or terminal emulator.
3. Connect the AC power cables to Power Supply 0 and Power Supply 1, and watch
the terminal for system messages.
Power supply 0
FIGURE 3-1
After the system controller boots, the system controller login prompt is displayed on
the serial console. The following example shows a partial output from the system
controller boot sequence leading to the login prompt.
CODE EXAMPLE 3-1
ALOM POST 1.0
Dual Port Memory Test, PASSED.
TTY External - Internal Loopback Test
36 Sun Fire T2000 Server Installation Guide • April 2006
Power supply 1
Rear Panel Power Connectors
Sample System Controller Output
