Slide Rail Assembly Notes

The rackmount kit has two slide rail assemblies. A slide rail assembly can be installed
on either the right or left side of the rack.
Each slide rail assembly consists of a three-section slide rail and a removeable
mounting bracket (
Mounting bracket
FIGURE 1-4
The front, middle, and rear sections form the slide rail. The middle and rear sections
■
have holes for mounting screws and adjust to fit rack depths from 24 in (61 cm) to
36.5 in (93 cm). The front section can be extended to allow movement of the
server out of the rack.
The removeable mounting bracket slides 14 in (36 cm) out of the slide rail, then
■
locks in place. If you unlock the mounting bracket at this point, it slides an
additional 12 in (30 cm) before separating from the slide rail. You can then mount
the mounting bracket to the right or left side of the Sun Fire T2000 chassis.
Note that there are a total of five locks (
■
are on the mounting bracket. One lock is on the front section of the slide rail. The
uses of these locks are described in the installation procedure in
8 Sun Fire T2000 Server Installation Guide • April 2006
).
FIGURE 1-4
Front section
Sections of the Slide Rail Assembly
Rear section
Middle section
) in a slide rail assembly. Four
FIGURE 1-5
Chapter 2.
