To Connect the SC Serial Management Port

▼
Use this port for server management. This port is needed to set up the SC network
management port, as detailed in
Management Port" on page
The SC serial management port is marked SER MGT. It is the leftmost RJ-45 port on
the rear of the chassis (
System Controller Serial Connection
FIGURE 2-18
●
Connect a Category 5 cable from the SC serial management port to the terminal
device.

To Connect the SC Network Management Port

▼
The SC network management port is marked NET MGT. It is the RJ-45 port above
the rear USB ports.
Note – This port is not operational until you configure the network settings
(through the serial managment port), as detailed in
Controller Network Management Port" on page
"Enabling the System Controller Network
38.
).
FIGURE 2-18
SER MGT
Chapter 2 Installing the Sun Fire T2000 Server
"To Configure the System
39.
